The Overflow Glass Reactor is engineered with borosilicate glass and a thermostatic jacket, this lifting reactor ensures efficient heating, cooling, and easy cleaning in pharmaceutical or chemical labs.
Feature:
Acid and alkali resistant（Except hydrofluoric acid, phosphoric acid, and concentrated alkali solution at high temperature）
Wide temperature range: -100℃~300℃
Stable Temperature Control
Heavy-Duty Steel Frame
Accept customized design
Model :
YMLGR-10EXOrder(MOQ) :
1 SetLead Time :
10~15 working daysOEM :
AcceptedPower Supply :
220V/50HZ
The Overflow Glass Reactor by Hefei Yangmai Technology Instrument Co., Ltd is specifically designed for temperature-sensitive reactions in pharmaceutical, chemical, and academic laboratories. The integrated lift system allows convenient access to the reactor vessel, simplifying operations such as cleaning, media exchange, or crystal collection. Its jacketed structure ensures uniform thermal circulation, suitable for both heating and cooling processes.
|
Model |
Volume(L) | Motor power（w） | Vaccum degree(Mpa) |
Speed (Ram) |
Torque (Ncm) |
Power supply | Size(Cm) |
| YMGR-01 | 1 | 40 | 0.096 | 50~600 | 30 | 220V/50HZ | 32*35*80 |
| YMGR-02 | 2 | 40 | 0.096 | 50~600 | 30 | 220V/50HZ | 32*35*80 |
| YMGR-05EX | 5 | 180 | 0.096 | 50~600 | 44 | 220V/50HZ | 45*45*110 |
| YMGR-10EX | 10 | 180 | 0.096 | 50~600 | 162 | 220V/50HZ | 50*50*120 |
| YMGR-20EX | 20 | 180 | 0.096 | 50~600 | 162 | 220V/50HZ | 50*50*145 |
| YMGR-30EX | 30 | 180 | 0.096 | 50~600 | 210 | 220V/50HZ | 50*50*160 |
| YMGR-50EX | 50 | 180 | 0.096 | 50~600 | 300 | 220V/50HZ | 60*60*180 |
| YMGR-100EX | 100 | 370 | 0.096 | 50~600 | 400 | 220V/50HZ | 70*70*260 |
| YMGR-150EX | 150 | 750 | 0.096 | 50~600 | 500 | 220V/50HZ | 85*85*290 |
| YMGR-200EX | 200 | 750 | 0.096 | 50~600 | 500 | 220V/50HZ | 90*90*300 |
1. Premium Lifting System
The integrated manual or motorized lift allows effortless adjustment of the reactor vessel for cleaning, sample collection, or media replacement, improving workflow efficiency and safety.
2. Durable Borosilicate Glass Construction
Made from high-grade borosilicate glass with excellent chemical and thermal resistance, ensuring stable operation under acidic, alkaline, or high-temperature conditions.
3. Double-Layer Jacket Design
The jacketed reactor body enables efficient circulation of heating or cooling fluid, maintaining precise temperature control during chemical reactions.
4. Vacuum and Pressure Compatibility
Supports both vacuum and low-pressure operations, suitable for distillation, reflux, crystallization, and solvent recovery processes.
5. High Torque Stirring Motor
Equipped with a brushless explosion-proof stirring motor for stable, long-term operation with adjustable speeds to suit various viscosities.
6. Modular and Expandable
Designed for easy integration with chillers, heaters, vacuum pumps, and condensers—ideal for continuous processing or closed-loop reactions
