5 L jacketed glass reactor is a versatile piece of equipment widely used in chemical, pharmaceutical, food, and biotech industries.
Feature:
Acid and alkali resistant（Except hydrofluoric acid, phosphoric acid, and concentrated alkali solution at high temperature）
Wide temperature range: -100℃~300℃
Transparent and easy to observe
Accept customized design
Model :
YMGR-05Order(MOQ) :
1 SetLead Time :
7~15 working daysOEM :
AcceptedPower Supply :
220V/50HZ
The 5L Desktop Jacketed Glass Reactor from Hefei Yangmai Technology Instrument Co., Ltd. is a compact, space-saving solution ideal for benchtop chemical synthesis, crystallization, and solvent evaporation. Featuring a double-layer borosilicate glass design, it allows precise temperature control from -80°C to 250°C using external heating or cooling circulation. This reactor is perfect for laboratory-scale research in pharmaceuticals, universities, and specialty chemical development, offering excellent visibility, chemical resistance, and easy integration into small lab spaces.
|
Model |
Volume(L) | Motor power（w） | Vaccum degree(Mpa) |
Speed (Ram) |
Torque (Ncm) |
Power supply | Size(Cm) |
| YMGR-01 | 1 | 40 | 0.096 | 50~600 | 30 | 220V/50HZ | 32*35*80 |
| YMGR-02 | 2 | 40 | 0.096 | 50~600 | 30 | 220V/50HZ | 32*35*80 |
| YMGR-05EX | 5 | 180 | 0.096 | 50~600 | 44 | 220V/50HZ | 45*45*110 |
| YMGR-10EX | 10 | 180 | 0.096 | 50~600 | 162 | 220V/50HZ | 50*50*120 |
| YMGR-20EX | 20 | 180 | 0.096 | 50~600 | 162 | 220V/50HZ | 50*50*145 |
| YMGR-30EX | 30 | 180 | 0.096 | 50~600 | 210 | 220V/50HZ | 50*50*160 |
| YMGR-50EX | 50 | 180 | 0.096 | 50~600 | 300 | 220V/50HZ | 60*60*180 |
| YMGR-100EX | 100 | 370 | 0.096 | 50~600 | 400 | 220V/50HZ | 70*70*260 |
| YMGR-150EX | 150 | 750 | 0.096 | 50~600 | 500 | 220V/50HZ | 85*85*290 |
| YMGR-200EX | 200 | 750 | 0.096 | 50~600 | 500 | 220V/50HZ | 90*90*300 |
1.Optimal Size for Research & Pilot Trials
The 5L capacity strikes the perfect balance between small-scale lab experiments and pre-production testing, making it ideal for process optimization and reaction development.
2.Precision Temperature Control via Jacketed Design
The double-layer borosilicate glass jacket supports accurate thermal exchange, compatible with thermostats or chillers for controlled heating/cooling from -80°C to 250°C.
3.Durable, High-Transparency Borosilicate Glass
Allows full visibility of reaction progress while offering strong resistance to corrosion, pressure changes, and aggressive solvents like ethanol or nitric acid.
4.Versatile Reaction Capabilities
Suitable for crystallization, extraction, solvent recovery, and chemical synthesis, including sensitive processes like acid-base reactions and oxidations.
5.Space-Efficient Benchtop Configuration
Designed for compact installation in fume hoods or lab benches, with a sturdy frame and casters for flexibility and safety.
6.Modular, User-Centric System
Supports various attachments—vacuum pumps, condensers, dosing pumps—making it easy to customize for specialty applications or scaled workflows.
